Выбор запчасти
Например
XLRAS47XS5E701948
| Код | Кол-во | Примечание |
|---|---|---|
| 1 Выпускной коллектор | ||
|
001
|
|
|
|
001
|
|
|
| 2 air inlet gasket | ||
|
002
|
|
|
|
001
|
|
|
| 3 flange bolt 10.9 | ||
|
007
|
M10X105
|
|
|
001
|
|
|
| 4 flange bolt 10.9 | ||
|
002
|
M10X90
|
|
|
006
|
|
|
| 5 adapter bush | ||
|
018
|
|
|
|
002
|
|
|
| 6 flange bolt 10.9 | ||
|
018
|
M10X75
|
|
| 7 heat shield, front exhaust manifold | ||
|
001
|
|
|
|
003
|
M10X18-M10X105
|
|
| 8 flange bolt 10.9 | ||
|
003
|
M8X16
|
|
| 9 flange bolt 10.9 | ||
|
002
|
M10X50 10.9
|
|
|
001
|
|
|
| 10 flange bolt 10.9 | ||
|
004
|
M8X16
|
|
|
001
|
|
|
| 12 Топливный фильтр | ||
|
001
|
+ WASTEGATE
|
|
| 13 exhaust gasket, turbo charger | ||
|
001
|
|
|
|
002
|
|
|
| 14 stud, metric thread | ||
|
004
|
|
|
|
001
|
|
|
|
001
|
|
|
| 15 hexagon nut, metric thread | ||
|
004
|
M10
|
|
|
004
|
M8X90
|
|
| 16 oil pipe, delivery side | ||
|
001
|
|
|
|
001
|
|
|
| 17 flange gasket | ||
|
001
|
|
|
|
004
|
|
|
| 18 flange bolt 10.9 | ||
|
002
|
M8X35
|
|
|
001
|
|
|
| 19 Пустотелый винт | ||
|
001
|
|
|
| 20 copper sealing washer | ||
|
002
|
22x29x1.5 mm
|
|
| 21 Выхлопн. шланг | ||
|
001
|
|
|
| 22 flange gasket | ||
|
001
|
|
|
| 23 cylinder head screw with hexagon socket and metric thread | ||
|
002
|
M8X20
|
|
| 24 flange gasket | ||
|
001
|
|
|
| 25 cylinder head screw with hexagon socket and metric thread | ||
|
002
|
M8X20
|
|
| 26 heat shield, turbo charger | ||
|
001
|
|
|
| 27 flange bolt 10.9 | ||
|
005
|
M8X16
|
|
| 28 air inlet pipe, inlet manifold | ||
|
001
|
|
|
| 29 Пробка расширителя | ||
|
002
|
D=32mm
|
|
| 30 Гибкий шланг | ||
|
001
|
|
|
| 31 Хомут шланга | ||
|
002
|
D=70-92
|
|
|
002
|
D=70-92mm
|
|
| 32 flange bolt 10.9 | ||
|
001
|
M10X105
|
|
| 33 КрепЁжный угольник | ||
|
001
|
|
|
| 34 flange bolt 10.9 | ||
|
002
|
M10X20 10.9
|
|
| 35 flange bolt 10.9 | ||
|
002
|
M8X20 10.9
|
|
| 36 sealing plug, fine metric thread | ||
|
001
|
M16X1,5
|
|
| 37 copper sealing washer | ||
|
001
|
16.2x21.9x1.3mm
|
|
| 999 sealing plug, fine metric thread | ||
|
001
|
M16X1,5
|
|
|
001
|
|
|
-+
